The Land Rover Series Transfer Box Sump Gasket FRC1516 retails at:

£6.75 each + postage to UK Mainland customers.

International postage isn't a problem; please contact us for a quotation.



HNJFRC1516



£6.75 ea

ex VAT





Technical Specification

Service
Novus 34, a superior performance material with excellent mechanical properties, it is suitable for many applications including oils,
solvents, high pressure steam and gases including oxygen.

Approvals / Compliance
WRAS Potable Water: Registration No.
1406501
BAM (Oxygen service) up to 90
o
C and 160 bar
Complies with BS Specification 7531 Grade X
TA-LUFT (in accordance with VDI Guideline
2440)
GL Approval cert 37702 – 12HH


Typical Physical Properties
Thickness
1.5mm
Density
1.75g/cc
Tensile Strength
ASTM F152 9-11MPa
Compression
ASTM F36 9%
Recovery
ASTM F36 55% min
Residual Stress
BS 7531 (300C) 26MPa
DIN 52913
32MPa
Gas Leakage
BS 7531 <1.0cc/min
ASTM Oil 1
Thickness increase 1.0%
IRM 903 Oil
Thickness increase 2.5%
ASTM Fuel B
Thickness increase 3.0%


Land Rover Transfer Gear
